CMM Software
Accurate CMM Services is an approved Distributor of the top CMM Software, Verisurf. As the industry has evolved, so have the capabilities and technologies in metrology services.
CMM Software has kept pace with our industry. With user-friendly interfaces and enhanced capabilities, including 5-axis measuring, scanning, surface finish analysis, and non-contact inspection.
With over 25 years of experience specializing in Coordinate Measuring Machine sales and service, we have the expertise to match you with the best CMM Software.
As a distributor for Verisurf, we can keep our clients up to date on all new developments and software updates. With our strong partnerships with both our clients and our manufacturer, we have access to exclusive support materials, ensuring we can help with any of your CMM needs.
Call us today and see how we can help!
Verisurf - 3D Measuring Solutions
See the difference Verisurf can make in your manufacturing.
Manufacturers require more reporting, traceability, and continuity of data than ever before. Intelligent 3D CAD models are now the standard design authority in manufacturing and continue the digital thread throughout the manufacturing process.
Verisurf
3D Measurement Solutions, lets you see the difference between the
nominal CAD design and the finished machine part in real-time. Perfect for a fast, in-process first article or automated production inspection that improves your manufacturing enterprise.
Verisurf 2027 Features Highlighted
The Verisurf 2027 release introduces powerful new capabilities designed to make CMM inspection, programming, and reporting faster, smarter, and more connected. With advanced automation, improved measurement analysis, enhanced 5-axis inspection tools, and expanded digital traceability, Verisurf 2027 helps manufacturers streamline quality control, reduce programming time, and achieve greater consistency throughout the inspection process.
Key Highlights
QIF Digital Thread Integration & Inspection Workflow
- Connect CAD, CAM, CMM, and quality management systems using the Quality Information Framework (QIF) for improved data sharing and traceability.
- Automatically generate inspection plans from engineering-defined QIF data and export standardized inspection results.
- Preserve critical design information and measurement traceability throughout the manufacturing and inspection process.
Smarter CMM Programming & Automated Inspection Paths
- Automated Pathing: Generate inspection paths directly from CAD-defined surface points, reducing repetitive programming tasks.
- Unified Path Merging: Combine multiple inspection paths into simplified workflows while maintaining safe probe movement and measurement accuracy.
- Dynamic GoTo Vector Control: Improve probe positioning, clearance, and collision avoidance with intelligent CAD-defined movement directions.
Advanced 5-Axis Inspection & Programming Intelligence
- 5-Axis Shaft Vector Control: Visualize and simulate complex 5-axis CMM movements before running inspection programs.
- Improved Motion Planning: Optimize machine movement and reduce setup time for advanced multi-axis inspection applications.
- Automatic Fit Method Intelligence: Automatically select the appropriate probe compensation based on the chosen fit method, reducing setup errors and improving inspection consistency.
Enhanced Measurement Accuracy & Surface Analysis
- Discrete Data Extraction: Improve scan-based measurement accuracy by isolating relevant inspection data, reducing scan noise and processing time.
- Bidirectional Feature & Surface Analysis: Reuse existing measurement data for feature evaluation, surface profiles, and additional analysis without remeasuring parts.
- More Efficient Analysis: Generate additional inspection results from existing datasets while reducing duplicate programming and measurement efforts.
Streamlined Inspection Reporting & Visual Feedback
- Unified Visual Tolerance Status: Quickly identify measurement conditions with consistent visual indicators, including a new warning when measurements reach 80% of their tolerance limits.
- Centralized Report Pane: Review and edit inspection reports, characteristic IDs, nominal values, and tolerances from one convenient workspace.
- Visual Form Deviation Graphs: Add graphical representations of form errors directly to reports for easier analysis, troubleshooting, and communication.
Expanded GD&T Compliance & Dimensional Reporting
- ASME Y14.5 Rule #1 Compliance: Automatically evaluate and report Envelope Principle compliance for circles and cylinders, eliminating manual calculations.
- Minimum & Maximum Local Size Reporting: Display local diameter measurements alongside functional size for a more complete picture of manufactured features.
- Improved Quality Documentation: Produce more informative inspection reports that support engineering decisions, customer requirements, and standards-based quality control.
Verisurf 2027 continues to advance metrology with intelligent automation, connected inspection workflows, and powerful reporting capabilities that help manufacturers improve productivity and maintain confidence in their measurement results.
Verisurf AUTOMATE is a powerful CMM programming software that supports Renishaw REVO and PH-20 5-axis probing systems. Its unique features enable users to establish an integrated connection with Renishaw's I++ international standard communications protocol, reducing the need for custom probes and special fixturing. The software's 5-axis probing feature reduces the number of setups and probe changes, making inspection routines faster and more efficient.
One of the major benefits of 5-axis probing is that it measures points with a more efficient and accurate set of dynamic events than the traditional 3-axis configuration of automated CMMs. Additionally, 5-axis probing reduces the movement of the heavy mass of CMMs XYZ structure, diminishing the effects of inertia on CMMs accuracy at higher speeds. Verisurf AUTOMATE's custom clearance feature is also key in achieving the entry/exit of off-axis probing angles, making it easier to program inspection routines.
Accurate CMM Services proudly partners with Verisurf Software, helping clients implement Verisurf AUTOMATE. Its 5-axis programming feature uses an object-based live simulation program with click, drag, rotate, scroll, and push-pull commands, making it easy to program inspection routines while maintaining clearances and providing a visual representation of the true path display. With Verisurf AUTOMATE, users can achieve extensive productivity gains with 5-axis probing, making it a must-have software for any company looking to streamline their inspection processes.
